MODEL

MDR-60-5

MDR-60-12

MDR-60-24

MDR-60-48

   OUTPUT

DC VOLTAGE

5V

12V

24V

48V

RATED CURRENT

10A

5A

2.5A

1.25A

CURRENT RANGE

0 ~ 10A

0 ~5A

0 -2.5A

0-1.25A

RATED POWER

50W

60W

60W

60W

RIPPLE & NOISE (max.)

80mVp-p

120mVp-p

150mVp-p

200mVp-p

VOLTAGE ADJ. RANGE

5 -6V

12-15V

24 - 30V

48 ~ 56V

VOLTAGE TOLERANCE

±2.0%

±1.0%

±1.0%

±1.0%

LINE REGULATION

±1.0%

±1.0%

±1.0%

±1.0%

LOAD REGULATION

±1.5%

±1.0%

±1.0%

±1.0%

SETUP, RISE TIME

500ms, 30ms/230VAC 500ms, 30ms/115VAC at full load

HOLD UP TIME (Typ.)

50ms/230VAC 20ms/115VAC at full load

     INPUT

VOLTAGE RANGE

85 - 264VAC 120-370VDC

FREQUENCY RANGE

47 ~ 63Hz

EFFICIENCY (Typ.)

78%

86%

88%

87%

AC CURRENT (Typ.)

1.8A/115VAC 1A/230VAC

INRUSH CURRENT (Typ.)

COLD START 30A/115VAC,60A/230VAC

LEAKAGE CURRENT

<1mA/240VAC

 PROTECTION

OVERLOAD

105 - 150% rated output power

Protection type: Constant current limiting, recovers automatically after fault condition is removed

OVERVOLTAGE

6.25-7.25V

15.6 - 18V

31.2-36V

57.6 - 64.8V

Protection type: Shut down o/p voltage, re-power on to recover

FUNCTION

DC OK SIGNAL

Relay contact rating (max.): 30V/1A resistive

ENVIRONMENT

WORKING TEMP.

-20 - +70°C (Refer to "Derating Curve")

WORKING HUMIDITY

20 ~ 90% RH non-condensing

STORAGE TEMP., HUMIDITY

-40 ~ +85°C, 10 ~ 95% RH

TEMP. COEFFICIENT

±0.03%/°C (0 - 50°C)

VIBRATION

Component: 10 - 500Hz, 2G 10min./1 cycle, period for 60min. each along X, Y, Z axes; Mounting: Compliance to IEC60068-2-6

    OTHERS

MTBF

299.2K hrs min. MIL-HDBK-217F (25°C)

DIMENSION

40*90*100mm (W*H*D)

PACKING

0.33Kg; 42pcs/14.8Kg/0.82CUFT
