Product Introduction
General Specification:
|
Model |
S-120-5 |
S-120-12 |
S-120-15 |
S-120-24 |
|
DC output voltage |
5V |
12V |
15V |
24V |
|
Output voltage tolerance |
±2% |
±1% |
±1% |
±1% |
|
Rated output current |
24A |
10A |
8A |
5A |
|
Output current range |
0-24A |
0-10A |
0-8A |
0-5A |
|
Ripple and noise |
50mVp-p |
100mVp-p |
100mVp-p |
100mVp-p |
|
Inlet stability |
±0.5% |
±0.5% |
±0.3% |
±0.2% |
|
Load stability |
±1% |
±0.5% |
±0.3% |
±0.2% |
|
DC output power |
120W |
120W |
120W |
120W |
|
Efficiency |
79% |
84% |
85% |
85% |
|
Output voltage adjustment range |
±10% |
±10% |
±10% |
±10% |
|
AC input voltage range |
85~265VAC |
|||
|
Input current |
0.6A/115V 0.35A/230V |
|||
|
AC impulse current |
Cold-start current 15A/115V 30A/230V |
|||
|
Leakage current |
<0.75mA/240VAC |
|||
|
Overload protection |
105%~150% Type,PULSING HICCUP SHUTDOWN,Reset,auto recovery |
|||
|
Over-voltage protection |
115%~135% rated output power |
|||
|
Temperature coefficient |
±0.03%°C(0~50°C) |
|||
|
Setup rise hold up time |
800ms,50ms,20ms/115VAC 300ms,50ms,80ms/230VAC |
|||
|
Vibration |
10~500Hz,2G 10min./1cycle,Period for 60min,Each axes |
|||
|
Withstand voltage |
I/P-O/P:2.5KVAC I/P-FG:2KVAC O/P-FG:0.5KVAC |
|||
|
Isolation resistance |
I/P-O/P I/P-FG O/P-FG:500VDC/100MΩ |
|||
|
Working temperature and humidity |
-10°C~+60°C,20~90%RH |
|||
|
Store temperature and humidity |
-20°C~+85°C,10~95%RH |
|||
|
Unit size |
159*98*42mm |
|||
|
Carton dimension |
50pcs per carton/54.5×35×25.7Cm 0.049CBM |
|||
|
Weight |
0.5Kgs |
|||
|
Safety standards |
Design refer to UL1012,EN60950-1,EN61347-1,EN-61347-2 approved |
|||
|
EMC standards |
EN55015,EN55022,EN55024,EN61000-2,EN61000-3,EN61547 approved |
|||
