Model：

AD1205SWF

Power:

60W max.

Input：

100-240VAC 50/60Hz

Output Voltage:

12V

Output Current:

0.1-5A

Input current:

1.5A max.

Inrush Current:

65 Amps max. at 230VAC/50Hz,full load

Leakage Current:

0.25mA Max. at 264VAC input

Energy Efficiency Level VI :

CoC 5 / DoE 6 / CEC VI

No Load Power Consumption ：

＜0.15W

Protections：

Short Circuit /Over Current /Over Voltage

Short Circuit Protection (SCP)：

Protection to Zero Voltage

Over Voltage Protection (OVP):

≤Vout*150%

Over Current Protection (OCP):

110%-180%

Working TEMP.:

-20°C-50°C

Working Humidity：

5%-90% RH non-condensing

Storage TEMP.,Humidity and altitude:

-40℃ ~+70°C ambient temperature and a 5% to 95% relative humidity range throughout an altitude range of -60 meters to +5000 meters AMSL.

Input Plug:

 EU,US,UK,AU etc. type according to customer's choice

Certificates and approvals:

UL,GS,CE,EMC,SAA,FCC,CB,PSE,CCC,RoHS,REACH

EMI EMISSION:

Radiation Test&Conduction Test: EN 55022/FCC Part 15
Harmonic Test : EN 61000-3-2
Flicker Test : EN 61000-3-3

EMS IMMUNITY:

ESD  Test:EN 61000-4-2
RS    Test:EN 61000-4-3
EFT   Test:EN 61000-4-4
Surge Test:EN 61000-4-5
CS     Test:EN 61000-4-6
DIP    Test:EN 61000-4-11

MTBF:

100000 hours minimum at full load at 25℃ ambient

Life:

3-5 years alternative

Dimension:

150*56*35mm

Weight:

453g

Packing:

20PCS/CTN,40*30*20cm
