产品介绍



1.Product Specifications

Ups power supply for access control

Model: DC1205M-S

Power input: 220/110VAC

Power output: 12VDC,5A

Control electric locks or bolts directly

Lessen the load of access controller Save project wires

With UPS terminal which can connect with battery

Lower potential trouble

NC/NO output Control all kinds of electric locks

Has delay control circuit

Unlock delay time in 0~10S

Auto protective function

Dimension:183* 80 *73 mm

Dimensions

183*80 *73 mm

Input Voltage

220VAC/110VAC

Output Voltage

12VDC/5A

Output Contact

Access control, Electric Lock, Release Button

Time delay

0~10sec.

Standard Designe

Steel material, Painted

Protect Safely

Short Circuit protection

Suitable For

all kinds of electric locks

Optional

110VAC input can be customized
